Li, C.; Heller, N. J.; Tiskevich, C. J.; Moose, S. P.

Kernel composition traits in maize, including protein accumulation, are of broad interest. The amount of the most abundant proteins in maize endosperm, the -zeins, can vary dramatically among genotypes and in response to soil nitrogen supply. Targeted reductions in -zein accumulation can improve nitrogen utilization and the nutritional quality of maize grain but have traditionally required expensive and destructive phenotyping methods. The Floury2-RFP (Fl2-RFP) reporter gene enables rapid, non-destructive visualization of -zein accumulation in individual maize kernels under white light. This feature is due to the high expression level programmed by the Fl2 promoter, the stability of zein proteins, and the use of monomeric RFP, which emits fluorescence without the need for multimerization. This study aimed to develop a method to quickly document and quantify Fl2-RFP accumulation using camera or smartphone images of either ears or shelled kernels. Results show images of shelled kernels processed with FIJI software capture the Fl2-RFP reporter phenotype better than images of ears. Fl2-RFP confirms the strong maternal control of -zein accumulation and, like grain protein concentration, responds to soil nitrogen supply. The Fl2-RFP phenotyping pipeline effectively quantified Fl2-RFP accumulation by color features from both camera and smartphone images. Smartphone imaging of Fl2-RFP in a diverse population of inbreds followed by elastic net regression of extracted image features predicted kernel protein concentration, as measured by near-infrared spectroscopy, with moderate accuracy (R2 = 0.68, MAE = 0.76, RMSE = 0.93). The spectral features that were most predictive of kernel protein concentration varied depending on whether the background endosperm color was white or yellow. The integrated analysis of Fl2-RFP intensity and grain protein concentration indicates genetic variation for kernel protein accumulation and N-responsiveness that is distinct from the well-studied -zeins. Our findings highlight the Fl2-RFP reporter gene as a valuable tool for investigating the genetic complexity of grain protein concentration and associated traits in maize.
